The core host of Hifuture's split-type charging system. Supports power pooling and flexible intelligent allocation, dynamically distributing power to up to 16 charging terminals. Module utilization increased by 40%.
| Rated Power | 480~1440 kW |
|---|---|
| Input Voltage | 400Vac ±15% |
| Frequency | 50/60Hz |
| Power Factor | ≥0.99 |
| Harmonics | ≤5% |
| Output Voltage | 200~1000 VDC |
| Output Channels | Max 16 |
| Peak Efficiency | ≥95% |
| Voltage Accuracy | ≤±1% |
| Current Accuracy | ≤±1% |
| Ripple P-P | ≤±1% |
| Current Imbalance | ≤3% |
| Cooling | Air Cooling |
| Start Methods | QR / VIN / Card / Plug-and-Charge / Manual |
| Operating Temp | -30~60°C (derating above 50°C) |
| Storage Temp | -40~75°C |
| Humidity | 5~90% RH (non-condensing) |
| Altitude | ≤2000m |
| Dimensions | L1700 × W970 × H1980 mm |
Dynamically distributes total power to up to 16 terminals based on vehicle demand (SOC, model, etc.)
Supports hot-swappable capacity expansion without replacing the host unit
Module utilization increased by 40% compared to traditional fixed allocation
Single unit max power up to 1440kW, meeting megawatt-level supercharging needs
Match the model to your site type, traffic profile, and commercial rollout plan.
Suitable for project-based DC charging station construction and commercial operation.
Supports predictable daily charging demand for fleet, logistics, and service vehicles.
Fits destination and public parking locations requiring reliable DC fast charging.
Hifuture charging products are configured for overseas projects with global certifications, OCPP platform integration, and project-based customization support.
Get a customized quote from our engineering team. From single units to full station deployment, we've got you covered.
